GalaxyTM

GalaxyTM Ceiling Tiles are economic and provide an NRC of up to 50%.

A non-directional pattern offers a cleaner look, with fast and more efficient installation.

Special Features

  • 20-year lifetime system warranty to withstand temperature and humidity conditions up to 40°C/95% relative humidity without visible sagging when used with a USG T-bar grid suspension system.
  • Excellent sound absorption and protection.
  • High light reflectance, reduces light fixtures and energy use.
  • Excellent light reflective finish reduces light fixtures and energy use with up to 80%.
  • Non-combustible.
  • Lightweight, construction cost saving.
  • Available in optimized recycled content formulations to help maximize LEED recycled content contribution.
  • Contains a broad-spectrum antimicrobial additive on the face and back of the panel that provides resistance against the growth of mold and mildew.
  • Economical, all-purpose ceiling pattern available in various panel sizes and edge details.
Physical Properties
  • Panel size: 600 x 1200mm.
  • Thickness: 14mm.
  • Grid Spacing: 605 x 1210mm.
  • Edge Profile(s): Square edge
  • Noise Reduction Coefficient (NRC): 0.50
  • Ceiling Attenuation Class(CAC): 33dB
  • Light Reflection (LR): 0.86
  • Thermal Resistance: R-1.6
  • Fire Resistance: Class A : Flame Spread 25, Smoke developed : 50
  • Weight: 3.33 - 3.58 kg /M2
  • Sustainability: up to 45% recycled material.

Applications
  • Offices
  • Retail stores
  • Schools
  • Showrooms
  • Hospitals
  • Airports
  • Corridors

โบรชัวร์แคตตาล็อก
Related Products

Information provided are for reference purpose only and due care has been taken to ensure accuracy at time of publication. Products, specifications and requirements may vary according to geographical locations and applications. As each project is unique, please contact your local Siam Gypsum representative for further assessment.
