GalaxyTM
GalaxyTM Ceiling Tiles are economic and provide an NRC of up to 50%.
A non-directional pattern offers a cleaner look, with fast and more efficient installation.
Special Features
- 20-year lifetime system warranty to withstand temperature and humidity conditions up to 40°C/95% relative humidity without visible sagging when used with a USG T-bar grid suspension system.
- Excellent sound absorption and protection.
- High light reflectance, reduces light fixtures and energy use.
- Excellent light reflective finish reduces light fixtures and energy use with up to 80%.
- Non-combustible.
- Lightweight, construction cost saving.
- Available in optimized recycled content formulations to help maximize LEED recycled content contribution.
- Contains a broad-spectrum antimicrobial additive on the face and back of the panel that provides resistance against the growth of mold and mildew.
- Economical, all-purpose ceiling pattern available in various panel sizes and edge details.
Physical Properties
- Panel size: 600 x 1200mm.
- Thickness: 14mm.
- Grid Spacing: 605 x 1210mm.
- Edge Profile(s): Square edge
- Noise Reduction Coefficient (NRC): 0.50
- Ceiling Attenuation Class(CAC): 33dB
- Light Reflection (LR): 0.86
- Thermal Resistance: R-1.6
- Fire Resistance: Class A : Flame Spread 25, Smoke developed : 50
- Weight: 3.33 - 3.58 kg /M2
- Sustainability: up to 45% recycled material.
Applications
- Offices
- Retail stores
- Schools
- Showrooms
- Hospitals
- Airports
- Corridors
