Olympia Micro™ ClimaPlus™

Olympia MicroTM ClimaPlusTM

With micro perforations that provide a smoother look and suitable sound absorption, these panels offer upscale appearance at a mid-range price.

Olympia Micro™ ClimaPlus™ Acoustical Ceiling Panels offer high level light reflectance, mold and mildew resistance, ceiling attenuation and noise absorption, making them a perfect choice for classrooms, hotels, reception and lobby areas, restaurants and retail stores.

A non-directional pattern offers a cleaner look, with fast and more efficient installation.

Meets low-emitting emission test criteria prescribed by the Singapore Green Building Council (SGBC) following ASTM D5116-06 testing methods.

Special Features

  • ClimaPlus 30-year lifetime system warranty to withstand temperature and humidity conditions up to 49°C/99% relative humidity without visible sagging when used with a USG T-bar grid suspension system.
  • Excellent sound absorption and protection.
  • Reduce thermal transfer and energy loss.
  • Excellent light reflective finish reduces light fixtures and energy use with up to 80%.
  • Non-combustible.
  • Lightweight, construction cost saving.
  • Contains a broad-spectrum antimicrobial additive on the face and back of the panel that provides resistance against the growth of mold and mildew.
  • Available in optimized recycled content formulations to help maximize LEED recycled content contribution.
Physical Properties
  • Panel size: 593 x 593mm., 593 x 1194mm.
  • Thickness: 16mm.
  • Grid Spacing: 600 x 600mm., 600 x 1200mm.
  • Edge Profile(s): Square edge, Shadowline Tapered, Fineline Bevel
  • Noise Reduction Coefficient (NRC): 0.50
  • Ceiling Attenuation Class(CAC): 30-33 dB
  • Light Reflection (LR): 0.88
  • Thermal Resistance: R- 1.7
  • Fire Resistance: Class A : Flame Spread 25, Smoke developed : 50
  • Weight: 4.18 - 4.46 kg / M2
  • Sustainability: 46% recycled material.
Applications
  • Offices
  • Retail stores
  • Schools
  • Showrooms
  • Hospitals
  • Airports
  • Corridors
